Lydsto Cordless Robotic Pool Cleaner Automatic Swimming Pool Vacuum

Product name：Robotic Pool Cleaner P1 MINI

Material: ABS

Rated power :45w

Charging Time: 4 hours

Working Time: 60minutes

Waterproof Grade: IPX8 waterproof

Filter: 1250um

Rated Working Voltage:12 V

Adapter Rated Input Frequency: 50/60Hz

Adapter Rated Output Voltage: 12.6V

Operating temperature:-30℃~65℃

Filtration capacity：250um

Velocity of movement: 52.5ft/min (16Meters / min)

Water filtration: 1280GPH

Size: 25 * 25 * 25cm

Net Weight: 3.3kg

Package Size: 40* 39 * 25cm

Package Weight: 6 kg

Package List:

1 * Robotic Pool Cleaner

1 * Power Adapter (110-220V)

1 * Handle

1 * Flishing Hook

1 * User Manual

Instructions for use

1. Charge the battery with the provided adapter

(1) Before charging, please turn off the power of the cleaning robot

(2) The charging port should be cleaned before charging.

(3) The red charging indicator indicates that the battery is being charged.

(4) The charging indicator light is green, indicating that the charging has ended.

2. Press the button to open the cleaning robot and put the cleaning robot into the water.

3. When it touches the wall, it automatically moves in the opposite direction and starts cleaning the

pool.

4. The cleaning robot will stop running when the power level is low. The cleaning robot will be pulled tothe water near the edge ofthe pool when it is hooked from the handle with a special fishing hook.

5. Power off operation: When exiting the pool, the buzzer will turn on. Press the button to turn it offAfter use, be sure to clean the filter.

FAQ

(1) Please remove the cleaning scraper for the water inlet. dry cover:

2. The robot beeps and cannot operate after launching:

(1) Check the state of the charging indicator;

(2) Restart the machine after recharging;

(3) lf it still doesn't work, contact customer service.

3. No response after opening the robot:

(1) Plug in the charger and turn it on. the robot beeps, continue charging for 1 hour before entering the water (please

turn off the cleaning robot, beep Stop and charge). lf it does not work, the battery is abnormal and needs to be replaced.

(2) lf you still cannot open the machine after inserting the charger, please contact customer service to replace the components or machine;

(3) How to ensure that the robot can be successfully charged? Turn on the robot, put it in the pool, and see if it works.

4. Even when the robot is fully charged, it only goes in one direction and doesn't reverse when it touches a wall:

(1) Check whether the baffle of the water  outlet is stuck or blocked;(2) Take out the control box and start it separately to see if there is any abnormality;

(3) lf there is no other abnormality, the sensor is faulty, and the machine or control box needs to be replaced.

5. If the robot stops or gets stuck

The product itself does not have the

ability to overcome obstacles.You can do the following(1) When stopping, check whether the cleaning scraper is stuck;(2) Check whether the bottom of the pool is uneven;

(3) Check whether there are other objects stuck at the bottom of the machine.

6. The robot's running speed slows down and its suction becomes weak:(1) Clean the filter screen and check whether the filter is too dirty. if yes, you are advised to manually cleanthe product and perform routine maintenance.(2) The machine may be short of power.Clean it after it is ful.

7. The charging jack is corroded by electrolysis:

(1) Please note that after each use, wipe the charging pin, clean and dry it with a paper towel or cottonswab.

(2) Install the waterproof plug after each charge.
